LeCroy WaveRunner XI Series User Manual

WAVERUNNER XI SERIES
20 WRXi-OM-E Rev C
Measure Tools (standard)
Display any 8 parameters together with statistics, including their average, high, low, and standard deviations.
Histicons provide a fast, dynamic view of parameters and wave shape characteristics.
• amplitude
• area
• base
• cycles
• delay
• delta delay
• delta time @ level
• Dtrig time
• duration
• duty cycle
• fall time (90-10%, 80-20%, @ level)
• first
• frequency
• last
• level @ x
• MATLAB param
• maximum
• mean
• median
• minimum
• number of points
• overshoot+
• overshoot-
• peak-to-peak
• period
• phase
• rise time (10-90%, 20-80%, @ level)
• rms
• std. deviation
• time @ level
• top
• width
• width negative
• x @ minimum
• x @ maximum
Pass/Fail Testing
Test multiple parameters against selectable parameter limits at the same time. Pass or fail conditions can initiate
actions including: document to local or networked files, email the image of the failure, save waveforms, send a
pulse out at the front panel auxiliary BNC output, or (with GPIB option) send a GPIB SRQ.
General
• Auto Calibration: Ensures specified DC and timing accuracy is maintained for 1 year minimum.
• Power Requirements: Single phase, 100 to 240 V
rms
(±10%) at 50/60 Hz (±5%); or single phase, 100 to 120
V
rms
(±10%) at 400 Hz (±5%); Automatic AC voltage selection
Voltage Range:
90 to 264 V
rms
90 to 132 V
rms
Frequency Range:
47 to 63 Hz 380 to 420 Hz
