OPERATOR’S MANUAL
WRXi-OM-E Rev C 19
Interface
• Remote Control: Through Windows® Automation or LeCroy remote command set
• GPIB Port (optional): Supports IEEE-488.2
• Ethernet Port: 10/100Base-T Ethernet interface (RJ-45 connector)
• USB Ports: 5 USB ports (one at front of oscilloscope) support Windows compatible devices.
• External Monitor Port (standard): 15-pin D-Type SVGA compatible DB-15; connect a second monitor to use
dual monitor display mode
• Parallel Port: 1 standard
• Serial Port: DB-9 COM1 port (not for remote control of oscilloscope)
Auxiliary Input
Signal Types: Select External Trigger or Clock input on front panel.
Auxiliary Output
• Signal Types: Select from calibrator signal on front panel or control signals output from rear panel BNC.
• Calibrator Signal: 250 Hz to 1 MHz square wave or DC level; 50 mV to 1.0 V (selectable) into 1 kohms
• Control Signals: trigger enabled, trigger out, pass/fail status, or off
Math Tools (standard)
Display up to four math function traces (F1 to F4). The easy-to-use graphical interface simplifies setup of up to
two operations on each function trace. Function traces can be chained together to perform math-on-math.
• absolute value
• average (summed)
• average (continuous)
• copy
• derivative
• deskew (resample)
• difference (-)
• enhanced resolution (to 11 bits vertical)
• envelope
• exp (base e)
• exp (base 10)
• fft (power spectrum, magnitude, phase)
• floor
• histogram of 1,000 events
• integral
• invert (negate)
• ln (log base e)
• log (base 10)
• MATLAB math
• product (X)
• ratio (/)
• reciprocal
• rescale (with units)
• roof
• segment
• segment
• (sinx)/x
• square
• square root
• sum (+)
• trend (datalog) of 1,000 events
• zoom (identity)
