6-26 Maintenance
DRAM Clock : By SPD
DRAM Timing : By SPD
DRAM Command Rate : 2T Command
AGP & P2P Bridge Control
AGP Aperture Size : 64M
AGP Driving Control : Auto
AGP Fast Write : Disabled
AGP Master 1WS Write : Disabled
AGP Master 1WS Read : Disabled
CPU & PCI Bus Control
CPU & PCI Write Buffer : Enabled
PCI Master 0WS Write : Enabled
PCI Delay Transaction : Disabled
System BIOS Cacheable : Disabled
Video RAM Cacheable : Disabled
Video Share Memory size : 16M
Select Display Device : CRT+LCD
Panel Type : 01
Panel Outport Port : DIO
Panel Clock Mode : Single
Panel Bus Width : 24 Bits
Memory Parity/ECC Check : Disabled
INTERGRATED PERIPHERALS
VIA OnChip IDE Device
IDE DMA Transfer access : Enabled
IDDE Prefetch Mode : Enabled
IDE HDD Block Mode : Enabled
Onchip IDE Channel0 : Enabled
IDE Primary Master PIO : Auto
IDE Primary Slave PIO : Auto
IDE Primary Master UDMA : Auto
IDE Primary Slave UDMA : Auto
Onchip IDE Channel 1 : Enabled
IDE Secondary Master PIO : Auto
IDE Secondary Master UDMA : Auto
IDE Secondary Slave UDMA : Auto
VIA Onchip PCI Device
Realtek ALC650 : Enabled
Onchip USB Controller : Enabled
USB2.0 Controller : Enabled
USB Keyboard Support : Disabled
Super IO Device
Onboard FDC Controller : Disabled
Onboard Serial Port 1 : 3F8/IRQ4
Onboard Serial Port 2 : Disabled
UART Mode Select : Normal
Onboard Parallel Port : 378/IRQ7
Parallel Port Mode : SPP
Init Display First : PCI Slot
