LeCroy WaveSurfer 400 Series

7.6 FRONT PANEL ASSEMBLY
Item
Fig. No
Part Number Quantity Description Location
1 IWMSQ901661 13 SCREW TT2 (+) 3X8S E1-9, E2-4
2 IWMSQ901781 11 SCREW TAP bundle 2X6S(P) E3-11
3 IWKGM030711 6 WS KNOB SPACER S E4-6
4 IWKCM149211 6 RUBBER OVERMOLDED KNOB S E4-6
5 IWKGM030611 3 WS NOBE SPACER ML E4-3
6 IWTPS183211 3 SP WASHER E1-3
7 IWKCM149411 2 RUBBER OVERMOLDED KNOB L E4-2
8 IWKPS009711 2 RAG 70 E3-2
9 IWKCM149311 1 RUBBER OVERMOLDED KNOB M E4
10 IWMHK002251 1 LOCK WIRE SADDLE LWS-2.5S D4, E1
11 IWKBA805921 1 WS FRONT CHASSIS E1
12 IWKBA806711 1 WS BEZEL PLATE D2, D4
13 IWKGM029311 1 WS KEY RUBBER UL-I E3
14 IWMZT007871 2 GASKET UC-3E0564 UL-I E2-2
15 IWMZT006131 2 GASKET UC-300280 with tape E1, E2
16
IW
KGM030211 2 WS RUBBER FOOT UL-I D2-2
17
IW
KPA226011 1 WS422 NAME OVER LAY UL-1 E4
IW
KPA225911 1 WS424 NAME OVER LAY UL-1
IW
KPA225811 1 WS432 NAME OVER LAY UL-1
IW
KPA225711 1 WS434 NAME OVER LAY UL-1
IW
KPA225611 1 WS452 NAME OVER LAY UL-1
IW
KPA224211 1 WS454 NAME OVER LAY UL-1
18
IW
KPA226111 1 WS PROBUS OVERLAY 2CH E4
IW
KPA224111 1 WS PROBUS OVERLAY 4CH
19
IW
KPA225711 1 WS CONTROL OVERLAY 2CH E4
IW
KPA224011 1 WS CONTROL OVERLAY 4CH
20
IW
MKB130032 5 SCREW KB (+) 3X6S(NIP) E1-5
21
IW
528623002 1 NOISE SHIELD 43SM24 E1
22
IW
KPA221221 1 LOGO PANEL E4
23
IW
KCM149511 1 WS PANEL COVER UL-1 E4
24 IWMZT007951 5 GRIP FINGER- 97-655-02 E1
25 IWKPA224311 1 WS INPUT OVERLAY UL-1 E4
Mechanical Part & Removal 7-9
