5-26 Performance Verification Rev. D Sept 2007
Increase the frequency of the generator to the maximum input frequency for that
model, adjusting the amplitude so that the power remains constant and measure
the value of pk-pk. Record in Table 9.
Repeat the above 3 steps for Channel 2, (Bandwidth – CH2 10mv.lss s)
Channel 3 (Bandwidth – CH3 10mv.lss) & Channel 4 (Bandwidth – CH4
10mv.lss) substituting channel controls and input connector. Record the
measurements in Table 9.
