LEGRAND DX2 Series User Manual

▶ DX2‑D2C6 Label:
The label aached to DX2‑D2C6 helps you idenfy dierent channels.
• CC represents a contact closure sensor channel. There are ve CC channels: CC1 through CC5•
• DC represents a dry contact signal actuator channel. There are two DC channels: DC1 and DC2•
▶ DX2‑D2C6 hall eect sensor (reserved):
DX2‑D2C6 contains a built-in hall eect sensor, which can detect whether a door is open or closed. The
hall eect sensor is reserved for future use. Aer connecng DX2‑D2C6 to a managing device, this built-
in sensor will be detected and show up the web interface and SNMP MIB, which is normal.
▶
DX2‑D2C6 terminals, DIP switches, and LEDs:
Terminals, DIP switches, and LEDs are located in two rows as shown below.
Numbers Components
CC and DC channels.
• Top row:•
Four CC channels (CC2 - CC5).
Two DC channels (DC1 - DC2).
• Boom row:•
One CC channel (CC1).
See
Connecng Detectors/Switches to DX2-CC2 (on page 22) for how to
connect CC sensors or DC actuators.
28
