Numbers Components
CC and DC channels.
• Top row:•
2 CC channels (CC2 - CC3).
4 DC channels (DC1 - DC4).
• Boom row:•
One CC channel (CC1).
See
Connecng Detectors/Actuators to DX (on page 50) for how to
connect CC sensors or DC actuators.
Dip switches for conguring the Normal state of each CC channel. See
Adjusng DIP Switches (on page 53).
• Top row:•
Dip switch 1 controls CC2.
Dip switch 2 controls CC3.
• Boom row:•
Dip switch 1 controls CC1.
Note: Dip switches 3 and 4 in the top row and DIP switch 2 in the
boom row do not control any channel and can be ignored.
