2.4 Intercom Subsystem
The Legrand Intercom Subsystem consists of several components, including the IC5010
Selective Call 8-Location Distribution Module, IC5000 Room Unit, IC5002 Door Unit, IC5003
Video Door Unit, IC5004 Patio Unit and IC7000 Broadcast Room Unit. The IC5010 is installed in
the enclosure and is powered by the PW1030 power supply. While the Room, Door and Patio
Units are installed in individual room locations. The installation sheets included with all these
components are as follows:
IC5010 – (P/N 1507214) – Selective Call Intercom Module
IC5000 – (P/N IS-0386) – Selective Call Intercom Room Unit
IC5002 – (P/N IS-0387) – Selective Call Intercom Door Unit
IC5003 – (P/N IS-0426) – Selective Call Intercom Video Door Unit
IC5004 – (P/N IS-0388) – Selective Call Intercom Patio Unit
IC7000 – (P/N 1507223) – radiant Broadcast Intercom Room Station
IC7001 – (P/N 1308003) – radiant Selective Call Intercom Room Station
NOTE: All of these Intercom components should be installed and configured before
installing the Intuity System.
