2.0 Physical Installation
2.1 Network Subsystem
The Network Subsystem consists of an ISP Modem/Router, Switches (Legrand DA1458 and
PW1458 recommended), and possibly additional Wireless Access Points (WAPs) (Legrand
DA1104 recommended). We realize it is not always possible to utilize Legrand network
components, but it is highly recommended, as these products are tested to work with our system
and very familiar to our Technical Support staff in the event that support is required in the future.
2.1.1 Routers
Legrand recommends using the homeowner’s ISP (Internet Service Provider) WiFi Modem/Router
for the Legrand Intuity and Digital Audio Systems. If the ISP supplied Network Appliance is a modem
only (no router), a list of compatible routers can be found at http://www.legrand.us/onq/router-
compatibility.aspx .
2.1.2 Wireless Access Points
If additional WiFi is required, Legrand recommends the use of the Legrand DA1104 AC WAP.
The owner’s manual for the DA1104 AC (P/N 1308237) is available on the http://www.legrand.us
website. In addition, a list of compatible Wireless Access Points can be found at
http://www.legrand.us/onq/router-compatibility.aspx .
2.1.3 Switches
Legrand 8-Port Gigabit switch products (DA1008 and DA1458) expand the number of switch ports
available on the router. The DA1458 provides Power over Ethernet capabilities on 4 of its 8 ports to
power devices such as the Legrand IP Cameras. The owner’s manual for the DA1458 is P/N
1308145 and it is available on the http://www.legrand.us website.
NOTE: The DA1008 requires the purchase of a separate power supply which is P/N PW7760. The
DA1458 also requires the purchase of a separate power supply which is P/N PW1458.
