7.0 Adding Wired Devices
7.1 Adding a Security Subsystem
NOTE: Before adding a security system to Intuity, the security system must be installed
and commissioned. Consult with your security alarm professional before making any
changes to the security panel programming. It is important to understand what impact
these programming changes may have on the rest of the security system devices.
Honeywell Vista 15p/20p/21ip:
1. Key in Installer Code (or 4112 by default) plus [800] to enter program and installer mode.
2. Then press [*][189] and then [5100], [*][192] [51], [*][193] [61], [*][91] [82] (not required with
Vista firmware 10.23 or newer), [*][21] [11] [00] would keep Quick Arm enable off for both
keypads and Intuity.
3. For the Honeywell Vista 15p, the codes would be [*][189] [55], [*][192] [51], [*][193] [51],
[*][91] [82] (not required with Vista firmware 10.23 or newer), [*][21] [1] [0] would keep Quick
Arm enable off for both keypads and Intuity.
NOTE: The default keypad address for Honeywell Vista series panels is 16. By default,
Intuity uses keypad address 19 for partition 1 and keypad address 20 for partition 2. The
steps described above will enable Intuity address 19 on partition 1 and Intuity address 20
on partition 2. If they keypad has no text on the display, check the wiring and if correct, set
the address by power cycling the system, holding 1 and 3 on startup, then enter the
address (16) followed by *.
Interlogix Concord 4:
1. Key in [8][Installer Code] (or 4321 by default), then press [0][0] to enter program and installer
mode.
2. Then press [#] for system programming,
3. Press [#] for security, up/down to select the proper partition to configure and [#] to select.
4. Press up/down to select Quick Arm and [#] to select. [1] = off or [2] = on,
5. Press [#] to save, then [*][*][*], and up to select exit system programming and then [#].
Interlogix NetworX:
Program the NX-584 Automation Module according to its user manual (see page 10). To do so,
from any keypad enter [*][8] + Go to Program Code (9173 default). Enter the address [72][#] for
the NX-584. Use the following settings:
0. Option Flags – Use Default [Off = Binary]
1. Baud Rate – 6 = 38400 [38.4k]
2. Enabling the Transitions (2 Segments):
