Segment 1: Select options 2, 5, 6, 7, 8 (2 and 7 will be selected by default)
Segment 2: Use Default (1 and 2 will be selected)
3. Programming the Command/Request Enables (4 Segments):
Segment 1: Use Default (2, 4, 5, 6, 7 and 8 will be selected)
Segment 2: Use Default (1, 2, 3, 4, and 5 will be selected)
Segment 3: Use Default (1 will be selected)
Segment 4: Select options 4, 5, 6 and 7 (4 and 7 will be selected by default)
4. LCD Keypad Address (1 Segment) – Use Default (Address 192)
Next, program the security panel according to the user manual. From any keypad enter [*][8] + Go
to Program Code (9713 default). Enter the address 0# for the control panel. Finally, Location 23 –
Segment 1- Enable option 1 to allow quick arm.
NOTE: For further assistance with Security Configuration, contact Legrand Technical
Support or the Security System Installer.
DSC Power Series NEO:
This guide assumes that the programming in the panel is set to the default for all settings. The
default installer’s code is 5555. It also assumes that v5.0 of the Communicator is being used.
1. Enable the Alternate Communicator
From the keypad Enter [*][8][Installer Code]
Enter [382] to program communicator option 3
Scroll over to option 5 using the arrow keys and hit [*] enable
Enter [#] to save settings and back out to the main screen
2. Configure the Alternate Communicator
From the main programming screen enter [851] to program the alternate
communicator
Enter [006] for the subsection System Toggle Option 2
Disable option 1 and 2 and enable option 8. Leave all other settings at their default
level – The output should show - - 3 - - - - 8
Enter [#] to save settings and back out to the alternate communicator programming
screen
Enter [422] for the subsection Integration Account Code
Write down the 12 digit number assigned to this communicator for use in configuring
Intuity in the next step
Enter [#] to back out to the alternate communicator programming screen
Enter [423] for the subsection Integration Access Code
Program any 8 digit number in this section bt make sure to write it down for use in
configuring Intuity in the next section
