10 PORT ETHERNET SWITCH CONNECTIONS
The 10 Port Ethernet Switch provides 8 PoE Ports for the IP-DECT Server 6500 and IP-DECT Base Stations.
53.5V 2.43A - connect to the mains supply (or a battery backed output on the optional UPS) via the in-line
mains adapter provided.
PoE PORTS 1 to 8 - connect to the IP-DECT Server 6500 and IP-DECT Base Stations using RJ45 patch
leads/wall sockets. These connections can be extended to a maximum of 100 metres using Cat5e cable.
UPLINK2 - connect to the Matrix NENX IP50 PBX Ethernet Port using an RJ45 patch lead.
UPLINK1 - connect to an additional Ethernet Switch Uplink Port using an RJ45 patch lead. This connection
can be extended to a maximum of 100 metres using Cat5e cable. This will provide another 8 PoE Ports for
up to 8 more IP-DECT Base Stations - repeat for every additional 8 Base Stations.
MATRIX CONNECTION
The Matrix IP-PBX interfaces the Advent XT2 to the DECT equipment; it also gives access to an outside line
and allows zoning of calls.
24VDC - connect to the UPS via the in-line PSU module provided.
CO1 - connect to the Advent XT2 DECT 1 output using the RJ11/BT lead provided.
CO2 - connect to an external telephone line using the RJ11/BT lead provided.
CO3 - connect to the Advent XT2 DECT 2 output using the RJ11/BT lead provided.
SLT1 - connect to the CLI desk telephone via a BT master socket (cut plug off the RJ11/RJ11 lead provided).
ETHERNET - connect to the Uplink2 Port of the 10 Port Ethernet Switch using the RJ45 patch lead provided.
Note; in the event of a mains failure i.e. if the UPS batteries run flat or if a UPS is not fitted, the Matrix
connects CO1 to SLT1 and the Advent XT2 will only ring the CLI desk telephone.
IP-DECT SERVER 6500 PROGRAMMING
The IP-DECT Server 6500 must have its IP address set to 192.168.0.3.
Refer to the manufacturer’s installation guide for full instructions – see section 6 of this manual.
IP-DECT BASE STATION PROGRAMMING
IP-DECT Base Station IP addresses must start at 192.168.0.4 with RPN 4 and carry on sequentially.
Refer to the manufacturer’s installation guide for full instructions – see section 6 of this manual.
4 CHANNEL MULTI-CELL DECT REPEATERS
A maximum of three 4 Channel Multi-Cell Repeaters can be connected per IP-DECT Base Station. Repeaters
require a power connection only; they communicate with the Base Station via low power radio signals and
do not require a line connection. To maintain DECT coverage during a mains failure all Repeaters must be
connected to a battery backed 12V DC PSU.
REPEATER POSITIONING
Before installing power cables to Repeater positions, it is important that the optimum position for coverage
is established. Register the Repeater onto the IP-DECT Base then with the Repeater powered from a battery
walk away in the direction that cover is to be extended. When the red LED on the Repeater starts to flash it
is out of range and must be moved back towards the IP-DECT Base by a minimum of 5 metres before
selecting its final location. The LED should be steady green. See Repeater Deployment Rules on the
following page.
REPEATER PROGRAMMING
Refer to the manufacturer’s installation guide for full instructions – see section 6. A programming kit (P/No.
ZXT509) is required to program Repeaters, the Service Tool software can be downloaded via the link in
section 6 of this manual.
