Doc No. FM0814 issue 5 Page 35
Repeater
RPN +64
Repeater
RPN +192
Repeater
RPN +64
Repeater
RPN +128
Repeater
RPN +192
Repeater
RPN +64
Repeater
RPN +128
Repeater
RPN +192
Repeater
RPN +64
Repeater
RPN +128
Repeater
RPN +192
IP-DECT Base Station
RPN 4 →
IP-DECT Base Station
RPN 4 →
IP-DECT Base Station
RPN 4 →
IP-DECT Base Station
RPN 4 →
Repeater
RPN +128
21. IP-DECT 6500 SYSTEM INSTALLATION
3 REPEATER DEPLOYMENT EXAMPLES
3 Repeaters connected in a chain:
1 Repeater connected directly and 2 in a chain:
3 Repeaters connected directly:
Y-shaped 3 Repeater deployment:
