CS10/CS15 & GS Sensors, Pin Assignments and Sockets 145
A.2 GS08plus/GS12
Description Some applications require knowledge of the pin assignments for the instrument
ports.
In this chapter, the pin assignments and sockets for the instrument ports are
explained.
Ports at the instru-
ment underside
a) Clip on contacts (only GS12)
b) Lemo port (USB and serial)
GS_122
TRK
BT
PWR
ON
OFF
a
b
