CS10/CS15 & GS Sensors, Operation
Step Description

The CompactFlash card is inserted into a slot inside the top of the
CS10/CS15.
1. Refer to "Fixing the slot cover to the CS step-by-step". Loosen the screws
inside the slot cover on top of the CS10/CS15 using the screwdriver end of
the stylus.
2. Detach the slot cover from the CS10/CS15.
3. Slide the card firmly into the slot until it clicks into position.

Do not force the card into the slot.
4. The card must be held with the contacts facing the slot.
5. Attach the slot cover and tighten the screws.
6. To remove the card, detach the slot cover of the CS10/CS15.
7. Press the eject button next to the card slot twice.
8. Remove the CompactFlash card and attach the slot cover.
