CS10/CS15 & GS Sensors, Operation 65
Insert and remove
an SD card step-by-
step
Step Description
The SD card is inserted into a slot inside the top of the CS10/CS15.
1. Refer to "Fixing the slot cover to the CS step-by-step". Loosen the screws
inside the slot cover on top of the CS10/CS15 using the screwdriver end of
the stylus.
2. Detach the slot cover from the CS10/CS15.
3. Slide the card firmly into the slot until it clicks into position.
Do not force the card into the slot.
4. The card must be held with the contacts facing the slot.
CS_018
1
2
4
SD
CF
3
