Leica DM2000, Description of the System
16
2.5 Accessories
Components of the
spray support
The spray support is delivered with a storage bag that provides space for an extra
spray can.
Components of the
GPS support
Wheels Both DS2000 versions: The rear wheels are tubeless tyres; the
tyre pressure should be 2 bar.
Four-wheeled version: The front wheels are solid rubber tyres.
Support for
laptop or tablet
The support is designed to hold a Panasonic FZ G1 tablet. The incli-
nation of the support can be adjusted to the optimal viewing angle.
Spray support
(optional)
The spray support provides a holder for a vertical spray marker and
can be attached to both sides of the antenna box. When the spray
support is connected to the control unit, the valve of the spray can
be controlled by the software to mark a target on the ground.
GPS support
(optional)
The GPS support can be attached to the DS2000 to provide a
holder for a GPS pole.
Component Description
a) Holder for vertical spray
b) Cable for connecting the spray
support to the control unit
c) Locking lever (on each side)
a
b
c
012319_001
a) Upper part with pole clamp
b) Lower part with tightening screws
c) Storage bag
a
b
c
012324_001
