Leica DS2000 - Inserting the Battery; Mounting the Spray Support

Leica DM2000, Setup
20
3.4 Inserting the Battery
Insert the battery
3.5 Mounting the Spray Support
Type of spray paint Use only spray paint that functions in the following way:
• The valve has to be pressed horizontally.
• The paint emerges from the top of the valve and flows along the elongation of the
spray can (not perpendicular to it).
1. To open the battery compartment, turn the metallic ring and lift the cover of
the compartment.
2. Insert the battery with the battery connectors facing toward the front of the
DS2000.
3. Close the battery compartment and turn the ring to lock it.
012335_001
1
2
3
a) Horizontal pressure on the valve
b) Spray paint
b
a
012320_001
