Leica DM2000, Software
34
4.4.2 Review of Scan Data with the Open Project Function
Open an existing
project
4.5 Export of Scan Data
Export scan data
and inserted
targets
Click this button to activate the “Scan Line Selection” mode.
To select a single scan line on the defined grid, click a line while this mode
is active.
To select several lines, click and drag to create a selection frame over the
lines.
This function is available before starting an acquisition.
Click this button to display or hide the grid on the radargrams.
Click this button to delete the scan data and markers of the currently
selected scan.
Click this button to view the current settings.
The settings cannot be changed from within a project. To change
the settings, return to the main menu and click the Settings
button.
Click this button to close the current project and return to the main menu.
Button Description
1. Click the Open Project button in the main menu.
2. Select a project file from the file directory and click Open.
The Review Acquisition screen is displayed.
3. The Map section and the radargrams allow you to review the existing scan data
of the survey project.
4. For a detailed description of available functions, refer to "4.4.1 The Review
Acquisition Screen".
1. Click the Open Project button in the main menu.
2. Select a project file from the file directory and click Open.
The Review Acquisition screen is displayed.
3. To export the scan data and inserted targets of the project, click the export
button in the Review Acquisition menu.
4. Select a file format and click Export.
