Leica DM2000, Setup
19
3.2 Preparing the Antenna
Regulate the move-
ment and height of
the antenna
a) Two-wheeled version
• For transportation, push the lever to the left position.
• When using the DS2000 in rough terrain, push the lever to the middle position. The
antenna has limited mobility.
• When using the DS2000 in smooth terrain, push the lever to the right position. The
movement of the antenna is blocked.
b) Four-wheeled version
To raise the antenna slightly from the ground, pull the strap on the top of the antenna
box.
3.3 Attaching and Connecting the Laptop or Tablet
Attach and connect
the laptop/tablet
012317_001
a b
The support is designed to hold a Panasonic FZ G1 laptop. When using a
different type of laptop or tablet, unscrew and remove the small plastic panel
on top of the support.
The support has several Velcro strips to allow fixing a tablet or laptop.
If necessary, attach the spare Velcro strips delivered with the DS2000 to the
currently used tablet or laptop.
1. To attach the laptop or tablet to the support, press it onto the support until
the Velcro strips are securely attached to each other.
2. Connect the laptop or tablet to the Ethernet cable of the DS2000.
012569_001
012570_001
