NOVOLAS Basic AT
Operation 43
Register
Index
Name Function Units Value range
103 I_s Actual current
emitted by the
current source
0.1A 0-4095, current capability depends on
current source module.
With the Air Cooled Laser Module, the unit is
0.01A)
109 T_Pyro Measured
temperature value
of pyrometer
- The unit depends on the value of bit 0 in
register 1. If this bit is set, the value is the
equivalent temperature of a blackbody
multiplied by 10. If this bit is not set, the raw
pyrometer measurements are displayed.
Register 120: The function of the values depends on the type of current source that is used.
120 Current Source (Standard Version)
120 Error Actual error value 0: NO ERROR: No Error
1: LUMV_MISSING: Current source is
connected but 5V output is below
threshold current value.
Bit coded
2: GATE SIGNAL TIMEOUT: The
activation-signal (typically from CIO)
has not been repeated quickly enough
during the activation phase.
Communication problem between CIO
and Laser module?
120 Current Source: air cooled laser module
120 Error Actual error value 0 NO ERR: no error
1 TEMP_1: Error Temperature 1
2 TEMP_2: Error Temperature 2
4 TEMP_3: Error Temperature 3
8 TEMP_4: Error Temperature 4
16 CONTROLTEMP: Temperature Error
in Laser diode
32 CURRENT LIMIT: Current error in
laser diode.
Check configuration. Take note of the
max current.
128 CURRENTSOURCE: Common error
in current source
Bit coded
♦
256 CURRENTSOURCE_VERSION:
wrong version of current source.
♦
Wenn bei bitcodierten Registern ein Wert steht, der nicht in der Liste aufgeführt ist, bedeutet dies,
dass mehrere Fehler gemeinsam auftreten. Wert 160 in Register 120 beudeutet beispielsweise,
dass die Fehler CURRENT LIMIT und CURRENTSOURCE auftreten.
