5.4303.8558.0 -
4-26 Description and Operation
4.3.3.11 Emergency Button
Display Description
The menu Emergency button displays the status of the
emergency stop button and the amount of times it was activated.
• Current mode:
• On: the button is currently activated.
• Off: the button is currently not activated.
• Switch counter: the amount of times the emergency stop
button is activated during its lifetime.
• Last switch: the date and time of the last moment that the
emergency button was pushed.
• Current mode A:
• On: Emergency stop button is currently activated with
contact A of the button activated.
• Off: emergency stop button is deactivated or activated.
Contact A is not activated.
• Current mode B:
• On: Emergency stop button is currently activated with
contact B of the button activated.
• Off: emergency stop button is deactivated or activated.
Contact B is not activated.
Buttons
•
to return to the menu Testing.
•
to enter the menu Manual control.
in n o vato rs in agriculture
