12. Attach the two hydraulic hoses to the support on the headstock.
Always keep the ball valve on the hydraulic system closed. If the ball valve is
open, the hydraulic pressure is released and the Splendimo will be unstable.
13.
Disconnect the top link from the headstock.
14. Disconnect the two lower arms from the linkage pins on the headstock.
15. Remove the ram-lock operating cord from the tractor cab.
16. Remove the tractor from the area.
Figure 6. Parking Position
CAUTION
Operation 3-3
M-H025.1011EN
