3.3 Move the Splendimo to the Transport Position
Make sure there are no persons in the area when you move the Splendimo
to the transport position.
Make sure the front axle weight of the tractor is sufficient (use front weights if
necessary) and that you do not exceed the rear axle weight when the
Splendimo is in the transport position.
Use all lights and warning signals as defined by your local road traffic
regulations.
1.
Disengage the PTO shaft.
Wait for all moving parts of the Splendimo to stop.
2. Pull the operating cord to release the locking hook on the hydraulic ram.
3. Operate the tractor hydraulic system to retract the hydraulic rams until
the Splendimo is in the transport position.
4. Make sure the locking hook has engaged in the hydraulic ram.
Make sure the PTO shaft does not turn when the Splendimo is in the
transport position.
Figure 7. Transport Position
WARNING
CAUTION
CAUTION
WARNING
WARNING
3-4 Operation
M-H025.1011EN
