3.4 Move the Splendimo from the Transport Position to the Working
Position
Make sure there are no persons in the area when you move the Splendimo
to the headland position.
Make sure the PTO shaft does not turn when the Splendimo is in the
transport position.
1. Pull
the operating cord to release the locking hook on the hydraulic ram.
2. Operate the tractor hydraulic system to extend the hydraulic ram until
the Splendimo is in the working position.
Figure 8. Working Position
3.5 Move the Splendimo from the Working Position to the Headland
Position
1. Operate the tractor hydraulic system to lift the Splendimo to the
headland position.
Figure 9. Headland Position
WARNING
WARNING
Operation 3-5
M-H025.1011EN
