8. SPECIFICATIONS
8.1 Splendimo 240 MCR Specifications
Working width 2.40 m
Transport width 1.4 m
Transport height 3.40 m
Number of discs/knives 6/12
Mowing height ± 30 mm and higher
Infinitely adjustable via the top link
Approximate swath width 0.70 - 2.40 m
Range of operation ± 20º from the horizontal (relative to the
tractor)
PTO speed 540 rpm or 1000 rpm
Linkage Category II
Hydraulic connections 1 double-acting valve with floating position
Max. oil pressure 21.0 MPa (210 bar)
Rotor diameter 2 x 21 cm
Rotor width 180 cm
Rotor speed 890 rpm
Security 1200 Nm 4 plate slip clutch (K92/4)
Power requirement 51 kW (70 hp)
Approximate weight 1060 kg
All specifications may be changed without prior notice.
Note:
Specifications 8-1
M-H025.1011EN
