Lennox PRODIGY M2 User Manual

7. Economizer
Page 33
PRODIGYT M2 UNIT CONTROLLER
Table 27. Outdoor Air Control ECTO Parameter Summary
Control Parameter Control Value
No. Name Min Default Max.
Units Description
5.17
OAC_Dampr_St
art_Open_SP
0 2.51 10 R: Volt
Damper start open" setpoint for Outdoor Air Control. Level where fresh air
damper begins to open.
5.18
OAC_Dampr_F
ull_Open_SP
0 5.02 10 R: Volt
Damper full open" setpoint for Outdoor Air Control. Level where fresh air damp-
er is opened to maximum.
5.26
IAQ_Input_
Source/Mode
0 0 5 Option
IAQ input source and mode (0−3 operate only when blower is on).
0− DCV System IAQ. Either P298−3 or network IAQ.
1− DCV System IAQ. Either P298−3 or network IAQ with no OAT limits.
2− Outdoor Air Control Sensor A24 (A133_P194−6) (TB22−6).
3− Outdoor Air Control Sensor A24 (A133_P194−6) (TB22−6) with no OAT limits.
4− DCV System IAQ. Either P298−3 or network IAQ with blower on/auto operation.
5− DCV System IAQ. Either P298−3 or network IAQ with blower on/auto operation
with no OAT limits.
9.01
A01_control_
mode
0 0 11 Option
Analog output channel 1 control mode.
0 − No operation. Analog Output 1 off.
Enabled When Control
1− Occupied PID setpoint A
Unoccupied PID setpoint B
2− Occupied PID setpoint A
Unoccupied Staged output B
3− Occupied Staged output A
Unoccupied PID setpoint B
4− Occupied Staged output A
Unoccupied Staged output B
5− Blower On PID setpoint A
Blower Off PID setpoint B
6− Blower On PID setpoint A
Blower Off Staged output B
7− Blower On Staged output A
Blower Off PID setpoint B
8− Blower On Staged output A
Blower Off Staged output B
9 − DI2 (A133_P194−2) on PID setpoint B (1)
DI1 (A133_P194−1) on PID setpoint A (2)
Otherwise off
10− DI2 (A133_P194−2) on PID setpoint B (1)
DI1 (A133_P194−1) on Staged output A (2)
Otherwise off
11− DI2 (A133_P194−2) on Staged output B (1)
DI1 (A133_P194−1) on Staged output A (2)
Otherwise off
(1) −DI1 (A133_P194−2) doesn’t matter
(2) −DI2 (A133_P194−1) is off
9.02 AO1_SP_A
0
0
−0.5
0
127
5.00
0
2.5
255
10.0
0.5
5.0
Counts
R:Volts
M:"w.c.
N:"w.c.
Analog output channel 1 setpoint A
9.09
AO1_PID_P_
Constant
0 0 127 Counts Analog output channel 1 PID loop proportional constant.
9.10
AO1_PID_I_
Constant
0 0 127 Counts Analog output channel 1 PID loop integral constant.
