Lennox PRODIGY M2 User Manual

10. Discharge Air Control
Page 44
506457−01 05/10
To use example values, set the following parameters:
S ECTO 8.02 – DACC_RAT_RS_SP – Set to 70°F
S ECTO 8.03 – DACC_RAT_RS_Proportional_Band – Set to 10°F
S ECTO 8.04 – DACC_ RAT_ RS_Adjustment_Band − Set to 10°F (this setting enables DACC return air reset).
10.4. Discharge Air Cooling Total Reset Limit
ECTO 8.01 (default=10) defines the total DACC setpoint reset limit. This total limit is the sum of both return and outdoor
DACC resets. This parameter limits total DACC_SP adjustment band and overrides the adjustment bands for RAT and OAT
(ECTO 8.07 & 8.04) if necessary.
Table 31. Discharge Air Cooling ECTO Parameters Summary
Control Parameter
No. Name
Control Value
Min. Default Max
Units Description
5.04 CL_Staging 0 2 4 Option
Cooling staging options:
0− No cooling operation
1− Basic Tstat operation. Two cooling stages. Units with Economizers
Y1=Free Cooling, Y2=adds all mechanical stages.
2− Basic Tstat operation. Two cooling stages. Units with Economizers
Y1=Free Cooling, Y2=adds first stage of mechanical.
3− Basic Tstat operation. Three cooling stages. Y1 only = first stage, Y2 only =
second stage, Y1+Y2=third stage. Units with Economizers Y2 only adds
first stage of mechanical, Y1+Y2 adds first and second stage of mechani-
cal.
4− Discharge air control. Up to four stages.
6.01 System_Mode 0 0 12 Option
System mode of operation.
Control
Value System Mode Backup Mode
0 Local Thermostat None
1 Zone Sensor None
2 Zone Sensor Local Thermostat
3 Zone Sensor Return Air Sensor
4 Remote Demand None
5 Remote Demand Local Thermostat
6 Remote Demand Return Air Sensor
7 Remote Demand Zone Sensor
8 Future Use None
9 Future Use Local Thermostat
10 Future Use Return Air Sensor
11 Future Use Zone Sensor
12 A138 4−Stg. Tstat Interface None
7.16 DACC_OCP_SP
124
80
161
55
183
40
Counts Discharge Air Control Cooling setpoint during occupied period.
7.17
DACC_
UnOCP_SP
124
80
146
65
183
40
Counts
X:DegF
Discharge Air Control Cooling setpoint during unoccupied period.
7.18 DACC_Stg_DB
7
5
7
5
30
20
Counts
V:DegF
Discharge Air Control Cooling stage deadband.
7.19
DACC_&_FAC_
StgUp_Delay
0
0
45
180
225
900
Counts
B: Sec.
Discharge Air Control Cooling and Fresh Air Cooling stage−up delay.
7.20
DACC_&_FAC_
StgDn_Delay
0
0
30
120
150
600
Counts
B: Sec.
Discharge Air Control Cooling and Fresh Air Cooling stage−down time delay.
7.21 DACC_Stg_Diff
3
2
3
2
30
20
Counts
V:DegF
Discharge Air Cooling stage differential.
8.01
DACC_RS_
Total_LT
7
5
15
10
29
20
Counts
V:DegF
Discharge Air Control Cooling total reset limit. This limits the total DACC reset
allowed. Also used to reset free cooling setpoint (6.23).
8.02
DACC_RAT_RS
_SP
124
80
139
70
169
50
Counts
X:DegF
Discharge Air Control Cooling return air reset setpoint. Also used to reset free
cooling setpoint (6.23).
8.03
DACC_RAT_
RS_Proportion-
al_ Band.
1
1
15
10
44
30
Counts
V:DegF
Discharge Air Control Cooling return air reset proportional band. Also used to
reset free cooling setpoint (6.23).
8.04
DACC_RAT_
RS_ Adjust_
Band
0
0
0
0
44
30
Counts
V:DegF
Discharge Air Control Cooling return air reset adjustment band.
0 disables return air cooling reset. Also used to reset free cooling setpoint
(6.23).
8.05
DACC_OAT_
RS_SP
50
100
81
80
144
40
Counts
Y:DegF
Discharge Air Control Cooling outdoor air temperature cooling reset setpoint.
Also used to reset free cooling setpoint (6.23).
