11. Third−Party Zoning
Page 52
506457−01 05/10
ECTO
No.
DescriptionSetting Required
Default
Setting
Name
Discharge Air Control Setup for Heating
5.09 HT_Staging 2 1
Option 1 sets control to operate discharge air control heating when W1 is
energized.
7.10 DACH_OCP_SP 110 Select 80−140F Discharge Air Control Heating setpoint during occupied period.
7.11 DACH_UnOCP_ SP 100 Select 80−140F Discharge Air Control Heating setpoint during unoccupied period.
7.12 DACH_Stg_DB 5F
Select 5−20F
(Recommend
default)
Discharge Air Control Heating deadband.
7.13
DACH_&_FAC_
StgUp_Delay
180 Sec.
Select 0−900Sec.
(Recommend
default)
Discharge Air Control Heating and Fresh Air Heating stage−up time delay.
Discharge Air Control Setup for Heating
ECTO
No.
Name
Default
Setting
Setting Required Description
7.14
DACH_&_FAC_
SgDn_Delay
120 Sec.
Select 0−600Sec.
(Recommend
default)
Discharge Air Control Heating and Fresh Air Heating stage−down time delay.
7.15 DACH_Stg_Diff 2F
Select 2−20F
(Recommend
default)
Discharge Air Control Heating stage differential
8.08 DACH_RS_Limit 10F
Select 5−20F. (Rec-
ommend default)
Discharge Air Control Heating reset limit. This limits the total DACH reset
allowed.
8.09 DACH_RAT_RS_SP 70F Select 50−80F. Discharge Air Control Heating return air heating reset setpoint.
8.10
DACH_RAT_RS_
Proportional_ Band.
10F Select 1−30F. Discharge Air Control Heating return air heating reset proportional band.
8.11
DACH_RAT_RS_
Adjust_Band
0F
(disabled)
Select 0−30F.
Discharge Air Control Heating return reset adjustment band. 0 value disables
return air heating reset.
8.12 DACH_OAT_RS_SP 40F Select −31−60F. Discharge Air Control Heating outdoor temperature reset setpoint.
8.13
DACH_OAT_RS_
Proportional_ Band.
20F Select 1−60F. Discharge Air Control Heating temperature reset proportional band.
8.14
DACH_OAT_RS_
Adjust_Band
0F (dis-
abled)
Select 0−30F.
Discharge Air Control Heating outdoor temperature reset adjustment band. 0
disables outdoor temperature heating reset
table continued on next page
