Lennox PRODIGY M2

12. BACnet®
Page 57
PRODIGYT M2 UNIT CONTROLLER
Table 36. Analog Input Objects List
Object ID Object Name Units Data Range
198 Mac Address None 0 − 127
199 M2 Address None 1−31
200* M2 Version[4] None 0 − 127
201* M2 Version[5] None 0 − 127
202* M2 Version[6] None 0 − 127
203* M2 Version[7] None 0 − 127
204* M2 Version[8] None 0 − 127
205* M2 Version[9] None 0 − 127
206* M2 Version[10] None 0 − 127
207* M2 Version[11] None 0 − 127
231 Unit ID None 0 − 127
232 Unit Status None 0 − 255
239 Space Temperature Deg. F 63.75 − 100.00
240 Discharge Air Temperature Deg. F −8.7 – 164.4
241 Effective Occupancy None 0 − 2
242 Local Outside Air Temperature Deg. F −30.6 – 131.6
243 Local Space Temperature Deg. F 63.75 – 100.00
244 Outside Air Damper Percent 0 − 100, 255
245 Heat Primary Percent 0 – 100
246 Heat Secondary Percent 0 – 100
247 Cool Primary Percent 0 – 100
248 Economizer Enabled Percent 0, 1, 255
250 Supply Fan Status Percent 0 − 100
252 Space Temperature Set Point (Eff) Deg. F 40.0 – 95.0
253 Current Error None 0 − 255
254 Error Pointer None 0 – 83
255 Most recent Error 1 None 1 − 255
256 Most recent Error 2 None 1 − 255
257 Most recent Error 3 None 1 − 255
258 Most recent Error 4 None 1 − 255
259 Most recent Error 5 None 1 − 255
260 Most recent Error 6 None 1 − 255
261 Most recent Error 7 None 1 − 255
262 Most recent Error 8 None 1 − 255
263 Most recent Error 9 None 1 − 255
264 Most recent Error 10 None 1 − 255
274 Space CO2 Sensor (Eff) Parts−per−million 0 − 2000
275 Space CO2 Sensor (Local) Parts−per−million 0 − 2000
276 Space Humidity (Eff) Percent 0 − 100
277 Space Humidity (Local) Percent 0 − 100
278 Dehumidification Set Point (Eff) Percent 0 − 100
279 Dehumidification Status None 0 − 2
281 Return Air Temperature Deg. F −8.7 – 164.4
282 Building Static Pressure Inches of water −0.5 − 0.5
283 Duct Static Pressure Inches of water 0 – 5.00
285 Exhaust Fan Status Percent 0 − 100
* Not recommended for new installations; legacy support only
