17. Electronic Configure To Order (ECTO) Control Parameters
Page 67
PRODIGYT M2 UNIT CONTROLLER
The unit controller software can directly access a unit by plugging into the M2 board phone jack and connecting to a serial
port using a PC converter. Any unit on the same daisy−chained network can be adjusted from any unit M2 board or the NCP.
A LAN ethernet converter and phone modem are also available for remote connections.
Table 41. M2 ECTO Control Parameters
Control Parameter
No. Name
Control Value
Min. Default Max.
Units Description
A BOX 3−5 ton Block 0 MSAV Parameters
0.01
Supply_VAV_
Control_Mode
0
0 (6 ton)
64 (3,4,5 ton Std Eff)
68 (3 ton High Eff)
72 (4 ton High Eff)
76 (5 ton High Eff)
255 Option
Supply VAV control mode selection by weight:
4 − MCB 3 ton direct drive
8 − MCB 4 ton direct drive
12 − MCB 5 ton direct drive
16 − MCB indoor blower high speed when running on OCP
32 − MCB indoor blower high speed when running on G
64 − MCB exists
0.02
VAV_SMK_
Stg_Output
0
0
55 (3,4,5 ton Std Eff)
55 (3 ton High Eff)
80 (4 ton High Eff)
59 (5 ton High Eff)
100
100
Counts
P: %
Blower staged % output during smoke detection.
0.04
VAV_HT_
Stg_Output
0
0
55 (3,4,5 ton Std Eff)
55 (3 ton High Eff)
80 (4 ton High Eff)
59 (5 ton High Eff)
100
100
P: %
Blower staged % output high speed; used for heating and high cooling
or ventilation.
0.05
VAV_CL_
Stg_1_Output
0
0
28 (3,4,5 ton Std Eff)
28 (3 ton High Eff)
40 (4 ton High Eff)
36 (5 ton High Eff)
100
100
P: % Blower staged % output low speed; used for low cooling or ventilation.
0.09
VAV_HT_
Stg_Output
0
0
30
30
100
100
P: %
Minimum damper position during low speed blower operation. Use
ECTO 5.24 during high speed blower operation.
0.27
Free_CL_Stg_
Up_Delay
0
0
38
304
255
2040
Counts
C: Sec
Free cooling blower stage−up delay. Blower runs low speed during
delay, and then shifts to high speed. Set to 0 for immediate high
speed, or XXX to stay in low speed.
A (6 ton), B, C, D, & E BOXES Block 0 VAV, CAVB, & MSAV Parameters
0.01
Supply_VAV_
Control_Mode
0 0 63 Option
Add the weights for each control description to determine option.
Weight− Description
1− GP1 board present, DIP set to VAV mode for VAV or CAVB con-
trol action.
2− VAV control action. 0 for CAVB control action. See table 29.
The following weights are used for VAV:
4− PID control when smoke detected. 0 for staged
8− PID control when running ventilation. 0 for staged.
16− PID control when running cooling. 0 for staged.
32− PID control when running heating. 0 for staged
For VAV control action, either PID or staged control can be selected.
For CAVB control action, PID is automatically used. (Staged is not
available for CAVB). Configuration alarm will occur if GP board (W/
DIP set to VAV) is installed and at least one of the following ECTO
parameters value are not set to non−zero: ECTO 0.01, 0.23 or 8.16
0.02
VAV_Press_
SMK_ SP
0
0
51
1.00
255
5.0
Counts
N:"w.c.
VAV supply static pressure setpoint during smoke detection.
VAV_SMK_
Stg_ Output
0 51 100 P: % VAV staged % output during smoke detection.
0.03
VAV_ Press_
Vent_ SP
0
0
51
1.00
255
5.0
Counts
N:"w.c.
VAV supply static pressure setpoint during ventilation.
VAV_VT_ Stg_
Output
0 51 100 P:% VAV staged % output during ventilation and economizer free cooling.
0.04
VAV_ Press_
HT_SP
0
0
51
1.00
255
5.0
Counts
N:"w.c.
VAV supply static pressure setpoint during heating.
VAV_HT_Stg_O
utput
0 51 100 P:% VAV staged % output during heating.
0.05
VAV_Press_
CL_ SP
0
0
51
1.00
255
5.0
Counts
N:"w.c.
VAV supply static pressure setpoint during cooling.
VAV_CL_Stg_1
_ Output
0 51 100 P:% VAV staged % output while cooling compressor 1 is on.
table continued on next page
