17. Electronic Configure To Order (ECTO) Control Parameters
Page 77
PRODIGYT M2 UNIT CONTROLLER
Control Parameter
No. Name
DescriptionUnits
Control Value
Min. Default Max.
Block 5 Miscellaneous Parameters (continued)
5.24
Min_Damper_
Position
0
0
101
101
100
100
Counts
P: %
Minimum fresh air damper position during occupied operation. Value
of 101 allows adjustment by potentiometer on economizer board A55
only. When in global mode with A55 EM1 versions 2.01 and earlier,
only 101 should be used.
5.25
Zone_Sensor_
StartUp_ Delay
15
2
15
2
225
30
Counts
C:Min.
Start−up demand delay. Holds off all unit operation zone sensor and
CAVB applications. Hold off FAH−Reheat, FAC, FAH options and all
GP outputs.
May be used to stagger unit start−ups. Does NOT delay demands in
thermostat mode.
5.26
IAQ_Input_
Source/Mode
0 0 5 Option
IAQ input source and mode (0−3 operate only when blower is on).
0− DCV System IAQ. Either P298−3 or network IAQ.
1− DCV System IAQ. Either P298−3 or network IAQ with no OAT limits.
2− Outdoor Air Control Sensor A24 (A133_P194−6) (TB22−6).
3− Outdoor Air Control Sensor A24 (A133_P194−6) (TB22−6) with no
OAT limits.
4− DCV System IAQ. Either P298−3 or network IAQ with blower on/auto
operation.
5− DCV System IAQ. Either P298−3 or network IAQ with blower on/auto
operation with no OAT limits.
5.27
Net_Sig_
Sources
0 0 15 Option
Network Signal Sources
Weight Description
1− IAQ (A63)
2− Zone Temp. (A2)
4− Outdoor Enthalpy (A7)
8− Indoor RH (A91)
Option is sum of the weights for all input signals that are provided
remotely over the network.
Note: When network sensor is used the physical analog input is ig-
nored. Loss of sensor alarms will not occur unless network commu-
nication is lost for 5 minutes, or has not been established within 5
minutes after reset.
Block 6 System 1 Parameters
6.01 System_Mode 0 0 12 Option
System mode of operation.
Control System Backup
Value Mode Mode
0− Local Thermostat None
1− Zone Sensor None
2− Zone Sensor Local Thermostat
3− Zone Sensor Return Air Sensor
4− Remote Demand None
5− Remote Demand Local Thermostat
6− Remote Demand Return Air Sensor
7− Remote Demand Zone Sensor
6.02
OCP_HT_
BkUp_ SP
20
95
120
70
240
40
Counts
Z:DegF
Backup occupied heating setpoint. Used if the communications link is
lost for 5 minutes between the M2 and NCP. Used only with zone
sensor applications.
Setpoint temperature must be < or = (6.04 − 6.15).
6.03
UnOcp_HT_
BkUp_SP
20
95
160
60
240
40
Counts
Z:DegF
Backup unoccupied heating setpoint. Used if the communications link
is lost for 5 minutes between the M2 and NCP. Used only in zone
sensor applications. Setpoint temperature must be < or = (6.05 −
6.15).
6.04
Ocp_CL_
BkUp_ SP
20
95
100
75
240
40
Counts
Z:DegF
Backup occupied cooling setpoint. Used if the communications link is
lost for 5 minutes between the M2 and NCP. Used only in zone sen-
sor applications. Setpoint temperature must be > or = (6.02 + 6.15).
6.05
UnOcp_CL_
BkUp_SP
20
95
60
85
240
40
Counts
Z:DegF
Backup unoccupied cooling setpoint. Used if the communications link
is lost for 5 minutes between the M2 and NCP. Used only in zone
sensor applications. Setpoint temperature must be > or = (6.03 +
6.15).
6.06
Override_
Timer
0
0
28
3584
225
28800
Counts
E: Sec
After hours override timer. Only used on zone sensor applications
without a Network Control Panel (NCP).
6.07 HT_Stg_DB
4
1
4
1
15
3.75
Counts
W:DegF
Heating deadband. Used only with M2 zone sensor applications.
Deadband must be < or = 6.15 − 6.08.
table continued on next page
