17. Electronic Configure To Order (ECTO) Control Parameters
Page 81
PRODIGYT M2 UNIT CONTROLLER
Control Parameter
No. Name
DescriptionUnits
Control Value
Min. Default Max.
Block 7 System 2 Parameters (continued)
7.25
Load_Shed_
Option
0 0 15 Option
Load shedding option used to disable half of available mechanical
cooling.
Select the load shedding input signal source:
0− No load shedding.
1− Special case. Shed all compressors when DI−3 opens. M2 v7.07
and later.
2− EM1 GLO (A55_P265−3) (economizer DIP NOT set to global
mode).
4− DI1 (A133_P194−1, DIP set to GP)
6− DI2 (A133_P194−2, DIP set to GP)
8− DI1 (A133_P194−1, DIP set to MGV).
10− DI2 (A133_P194−2, DIP set to MGV)
12− DI1 (A133_P194−1, DIP set to VAV)
14− DI2 (A133_P194−2, DIP set to VAV)
These options select load shedding that will round up (fractional com-
pressors on).
1 compressor unit – compressor is not disabled.
3 compressor unit – only compressor 3 is disabled.
Add one to any option to select load shedding that will round
down (fractional compressors off).
1 compressor unit – compressor is disabled.
3 compressor unit – compressors 2 and 3 are disabled.
7.26 BACnet_MAC 0 128 128
Address /
Option
BACnet MAC Address. A value of 0−127 sets the BACnet MAC ad-
dress to that value; 128 sets the MAC address to the unit address set
on the ADDRESS DIP switch.
Block 8 System 3 Parameters
8.01
DACC_RS_
Total_LT
7
5
15
10
29
20
Counts
V:DegF
Discharge Air Control Cooling total reset limit. This limits the total DACC
reset allowed. Also used to reset free cooling setpoint (6.23).
8.02
DACC_RAT_RS
_SP
124
80
139
70
169
50
Counts
X:DegF
Discharge Air Control Cooling return air reset setpoint. Also used to
reset free cooling setpoint (6.23).
8.03
DACC_RAT_
RS_Proportion-
al_ Band.
1
1
15
10
44
30
Counts
V:DegF
Discharge Air Control Cooling return air reset proportional band. Also
used to reset free cooling setpoint (6.23).
8.04
DACC_RAT_
RS_ Adjust_
Band
0
0
0
0
44
30
Counts
V:DegF
Discharge Air Control Cooling return air reset adjustment band. 0
disables return air cooling reset. Also used to reset free cooling setpoint
(6.23).
8.05
DACC_OAT_
RS_SP
50
100
81
80
144
40
Counts
Y:DegF
Discharge Air Control Cooling outdoor air temperature cooling reset
setpoint. Also used to reset free cooling setpoint (6.23).
8.06
DACC_OAT_
RS_ Proportion-
al_ Band.
1
1
31
20
94
60
Counts
O:DegF
Discharge Air Control Cooling outdoor ambient temperature cooling
proportional band. Also used to reset free cooling setpoint (6.23).
8.07
DACC_OAT_
RS_ Adjust_
Band
0
0
0
0
47
30
Counts
O:DegF
Discharge Air Control Cooling outdoor temperature ambient cooling
adjustment reset band. 0 disables outdoor air cooling reset. Also used
to reset free cooling setpoint (6.23).
8.08
DACH_RS_
Limit
7
5
15
10
29
20
Counts
V:DegF
Discharge Air Control Heating reset limit. This limits the total DACH
reset allowed.
8.09
DACH_RAT_
RS_SP.
124
80
139
70
169
50
Counts
X:DegF
Discharge Air Control Heating return air heating reset setpoint.
8.10
DACH_RAT_
RS_Proportion-
al_ Band
1
1
15
10
44
30
Counts
V:DegF
Discharge Air Control Heating return air heating reset proportional
band.
8.11
DACH_RAT_
RS_Adjust_
Band
0
0
0
0
44
30
Counts
V:DegF
Discharge Air Control Heating return reset adjustment band.
0 value disables return air heating reset.
8.12
DACH_OAT_
RS_SP
113
60
144
40
255
−31
Counts
Y:DegF
Discharge Air Control Heating outdoor temperature reset setpoint.
8.13
DACH_OAT_R
S_Proportional_
Band.
1
1
31
20
94
60
Counts
O:DegF
Discharge Air Control Heating temperature reset proportional band.
8.14
DACH_OAT_R
S_Adjust_ Band
0
0
0
0
47
30
Counts
O:DegF
Discharge Air Control Heating outdoor temperature reset adjust-
ment band.
0 disables outdoor temperature heating reset
table continued on next page
