Figure101.InstallingthefrontWi-Fiantenna
7.ConnectthefrontantennacabletotheWi-Ficardmodule.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallationorreplacement,goto“Completingthepartsreplacement”onpage93.
RemovingthefrontWi-Fiantenna
ToremovethefrontWi-Fiantenna,dothefollowing:
1.Turnoffthecomputeranddisconnectallpowercordsfromelectricaloutlets.
2.Removethecomputercover.See“Removingthecomputercover”onpage32.
3.Removethefrontbezel.See“Removingandreinstallingthefrontbezel”onpage32.
4.Pressthereleasetab1asshownandpivotthedrivebayassemblyupward.
Figure102.Pivotingthedrivebayassemblyupward
Chapter5.Installingorreplacinghardware91
