8.Installthescrewtosecurethesecondaryharddiskdrivebrackettothechassis.
3
4
5
6 7
8
Figure49.Installingthescrewtosecurethesecondaryharddiskdrivebracket
9.Toinstallanewharddiskdriveintothebluebracket,exthebracketandalignpin1,pin2,pin3,
andpin4onthebracketwiththecorrespondingholesintheharddiskdrive.Donottouchthecircuit
board5onthebottomoftheharddiskdrive.
Figure50.Installingtheharddiskdriveintothebracket
56ThinkStationE32UserGuide
