Parameter data transfer
CTT2: Write parameter value
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
9.2 CTT2: Write parameter value
• Acyclic write request from master to slave:
• Response from slave to master is OK:
• Response from slave to master has failed:
Byte Contents / value
0 CTT2: Code
•Index 0x13 (19): Acyclic write request
1 CTT2: Index
•Index 0x18 (24): Write parameter value
2 CTT2: Number of bytes
• 0x8 (8)
3Index high
byte
Index = 0x5FFF (code to be written)
4Index low
byte
5Subindex
6 Data type / number of bytes
Bit 7 = 0 Number (4 data bytes):
• Bits 0 ... 2 = Number of valid bytes
(1 = 1 byte, 2 = 2 bytes, 3 = 3 bytes, 4 = 4 bytes)
Bit 7 must be "0". Writing the string is not supported.
7 Data byte 1 (MSB)
8 Data byte 2
9 Data byte 3
10 Data byte 4 (LSB)
Byte Contents / value
0 CTT2: Code
•Index 0x53 (83): Acyclic write request is OK.
• Parameter value was written.
Byte Contents / value
0 CTT2: Code
•Index 0x93 (147): Acyclic write request is not OK.
1 CTT2: Standard error code
CTT2: Standard error codes
( 51)
2Error code (MSB)
3Error code
4Error code
5Error code (LSB)
CTT2: Acyclic device error codes
( 52)
