1. If devices EVx9321 EVx9333 or 8200 vector are used in the drive
system:
Look for the rated powers of the connected motors in the table and write
down the corresponding powers P
DC
.
2. If devices ECSxAxxxC4B are used in the drive system:
Look for the connected axis modules in the table and write down the
corresponding powers P
DC
.
3. If required, determine the power P
DC
additionally available for the
devices EVx9335 EVx9338, EVx9381 EVx9383 in the drive system
by means of a rough estimate:
Device power ˘ rated power of the motor connected
4. Add all powers P
DC
from steps 1. and 2. and subtract the power P
DC
that is additionally available.
– The result is the input power required.
5. Select the 9360 DC power supply units to provide the input power.
10.5.3 Dimensioning examples
Drive data
Detemined power P
DC
Controller Motor
Drive Type Power
Drive 1 E82EV113K4C 11 kW 12.5 kW
from table
Drive 2 E82EV453K4B 37 kW 41 kW
Drive 3 EVS9332 75 kW 82 kW
Drive 4 ECSxA048C4B 18 kW
Drive 5
(input module)
EVV9336 (132 kW) 110 kW −22 kW rough
estimate
1. Determine the required DC power:
P
DC
+ 12.5kW ) 41kW ) 82kW ) 18kW * 22kW + 131.5kW
2. Determine the required 9360 DC power supply units:
If 1 × 9364 (50 kW) and 1 × 9365 (100 kW) are used, a sufficient DC power
is provided with 150 kW.
How to calculate the input
power required:
