Lenze 9300 vector - 7.2.4 Changing and saving parameters

Parameter setting
Parameter setting with the XT EMZ9371BC keypad
Changing and saving parameters
7
7.2
7.2.4

7.2−4
EDSVF9383V EN 6.0−11/2009
 Note!
Shortcuts with (:
Press and hold the ( key, then press a second key.
Key
Function
Menu level Code level Parameter level Operating level

Change to the
parameter level
Change to the
operating level
Change to the code
level
(
Load predefined
configurations in
the "Short setup"
menu
Accept parameters
if SHPRG ' or
SHPRG are
displayed

)
Change between
menu items
Change the code
number
Change the digit
via cursor
(
( )
Quick change
between menu
items
Quick change of
code number
Quick change of
digit via cursor

Change between main menu,
submenus, and code level
Cursor to the right
*
Cursor to the left

Deactivate the function of the + key, the LED in the key goes out
+
Inhibit the controller, the LED in the key is lit
Reset the fault
(TRIP reset):
1. Eliminate the cause of malfunction
2. Press +
3. Press 
1)
Only active if standard devices of the 8200 vector or 8200 motec series are used
7.2.4 Changing and saving parameters
 Note!
Your settings have an effect on the current parameters in the
main memory. You must save your settings in a parameter set so
that they are not lost when the mains are connected.
If you only need one parameter set, save your settings as
parameter set 1, since parameter set 1 is loaded automatically
after mains connection.
Step Key
sequence
Action
1. Select the menu  )  * Use the arrow keys to select the desired
menu
2. Change to the code level  Display of the first code in the menu
3. Select code or subcode ) 
Display of the current parameter value
4. Change to the parameter level 
5. When SHPRG is displayed,
inhibit the controller
+
1)
The drive coasts
6.
Change parameter
A  * Move cursor below the digit to be changed
B
)  Change of digit
( )
( 
Quick change of digit
Function keys
