Lenze 9300 vector - 3.7 Fuses and cable cross-sections; 3.7.1 Mains supply

Technical data
Fuses and cable cross−sections
Mains supply
3
3.7
3.7.1

3.7−1
EDSVF9383V EN 4.0−11/2007
3.7 Fuses and cable cross−sections
Field Description
Fuses and cable cross−sections All information given in this chapter are recommendations.
They refer to
l controllers installed in control cabinets.
l cables with a distance to the wall which is at least as wide
as the cable cross−section.
l a max. ambient temperature of +40 °C.
Selection of the cable
cross−section
Consider the voltage drop under load (£ 3 % acc. to
DIN 18015 part 1) for the selection.
Protection of the cables on the
AC side (L1, L2, L3)
On the AC side, the cables are protected by means of common
fuses.
Fuses in UL−conform plant must have UL approval.
Protection of the cables on the
motor side (U, V, W)
It is not necessary to fuse the motor cable.
Further information In the chapter "Wiring the basic device" ® "Important notes"
® "Device protection"
Standards and regulations The user is responsible for the compliance with national and
regional standards and regulations (e.g. VDE 0113, VDE 0298,
EN 60204).
3.7.1 Mains supply
For fusing the mains supply you can use the following fuses (gRL) and cable
cross−sections:
9300 vector Installation in accordance with EN 60204−1
Fuse Cable cross−sections
L1, L2, L3 PE
Type [A] [mm
2
] [mm
2
]
EVF9335−EV
EVF9335−EVVxxx
250
150
2 × 50
1)
95
EVF9336−EV
EVF9336−EVVxxx
315
150
2 × 50
1)
95
EVF9337−EV
EVF9337−EVVxxx
315
150
2 × 50
1)
95
EVF9338−EV
EVF9338−EVVxxx
400
240
2 × 95
1)
150
Master Slave Master Slave Master Slave
EVF9381−EV
EVF9381−EVVxxx
315 315
150
2 × 50
1)
150
2 × 50
1)
95 95
EVF9382−EV
EVF9382−EVVxxx
315 315
150
2 × 50
1)
150
2 × 50
1)
95 95
EVF9383−EV
EVF9383−EVVxxx
400 400
240
2 × 95
1)
240
2 × 95
1)
150 150
1)
Multiple conductor; both conductors must have the same cross−section
 Note!
We recommend to use semiconductor fuses (gRL).
Information about fuses and
cable cross−sections
