10.4 Fuses and cable cross−sections
10.4.1 Mains supply
For fusing the mains supply you can use the following fuses (gRL) and cable
cross−sections:
9300 vector Installation in accordance with EN 60204−1
Fuse Cable cross−sections
L1, L2, L3 PE
Type [A] [mm
2
] [mm
2
]
EVF9335−EV
EVF9335−EVVxxx
250
150
2 × 50
1)
95
EVF9336−EV
EVF9336−EVVxxx
315
150
2 × 50
1)
95
EVF9337−EV
EVF9337−EVVxxx
315
150
2 × 50
1)
95
EVF9338−EV
EVF9338−EVVxxx
400
240
2 × 95
1)
150
Master Slave Master Slave Master Slave
EVF9381−EV
EVF9381−EVVxxx
315 315
150
2 × 50
1)
150
2 × 50
1)
95 95
EVF9382−EV
EVF9382−EVVxxx
315 315
150
2 × 50
1)
150
2 × 50
1)
95 95
EVF9383−EV
EVF9383−EVVxxx
400 400
240
2 × 95
1)
240
2 × 95
1)
150 150
1)
Multiple conductor; both conductors must have the same cross−section
 Note!
We recommend to use semiconductor fuses (gRL).
