Safety engineering
Appendix
Module internal codes
1
123
EDS94AYAE EN 6.0
Index:Data type:Name:Parameter:
C15308 SS2 mode
UNSIGNED_8 9267
d
= 2433
h
Selection whether SS2 is to be executed already after reaching n=0 SOS or only after reaching the parameterised
stopping time.
Selection list
(Lenze setting bold) Information
0 SOS after stopping time
(As of SM301 V1.3)
1 SOS at n = 0
þ Read access Write access o Controller inhibit o PLC-STOP o No transfer
C15310 Tolerance window (n=0)
INTEGER_16 9265
d
= 2431
h
Safely monitored tolerance window for zero speed
Setting range
(min. value | unit | max. value) Information
0 rpm 16000 Lenze: 0
þ Read access Write access o Controller inhibit o PLC-STOP o No transfer
C15311 SOS: Tolerance window (Delta p=0)
UNSIGNED_32 9264
d
= 2430
h
Safely monitored tolerance window for zero position change
Display area
(min. value | unit | max. value) Information
0 Incr. 327680 Lenze: 0 (From SM301 V1.3)
þ Read access Write access o Controller inhibit o PLC-STOP o No transfer
C15312 SOS: Maximum change in position
UNSIGNED_32 9263
d
= 242F
h
Amount of the maximum change in position while SOS was active
Display area
(min. value | unit | max. value) Information
0 Incr. 2147483647 (From SM301 V1.3)
þ Read access o Write access o Controller inhibit o PLC-STOP o No transfer
C15315 SS1, SS2: ramp monitoring
UNSIGNED_8 9260
d
= 242C
h
Selection whether the brake ramp is to be monitored when SS1 and SS2 are executed.
Selection list
(Lenze setting bold) Information
0 No ramp monitoring
(From SM301 V1.4)
1 Ramp monitoring is activated
þ Read access Write access o Controller inhibit o PLC-STOP o No transfer
C15316 SS1, SS2: S−ramp time
UNSIGNED_8 9259
d
= 242B
h
S−ramp time of deceleration ramp for SS1 and SS2 if a linear ramp is not used.
Setting range
(min. value | unit | max. value) Information
0 % 100 0 (From SM301 V1.4)
þ Read access Write access o Controller inhibit o PLC-STOP o No transfer
C15317 SS1, SS2: Start offset ramp
UNSIGNED_8 9258
d
= 242A
h
Speed offset at the start of the ramp monitoring.
Display area
(min. value | unit | max. value) Information
0 % 30 0 (From SM301 V1.4)
þ Read access Write access o Controller inhibit o PLC-STOP o No transfer
C15320 SMS: Max. speed Nmax
INTEGER_16 9255
d
= 2427
h
Selection of the maximum speed and activation of the SMS function
Setting range
(min. value | unit | max. value) Information
0 rpm 16000 Lenze: 1, deactivate: 0
þ Read access Write access o Controller inhibit o PLC-STOP o No transfer
