Safety engineering
Appendix
Module internal codes
1
130
EDS94AYAE EN 6.0
Index:Data type:Name:Parameter:
8682
d
= 21EA
h
BITFIELD_64
Log stateC15893
Bit 4 SS1 via SD−In SS1 was triggered via a safe input.
Bit 5 SS1 via S−bus SS1 was triggered via the safety bus.
Bit 6 SS1 through error SS1 was triggered through an error.
Bit 7 Reserved −
Bit 8 SS2 via SD−In SS2 was triggered via a safe input.
Bit 9 SS2 via S−bus SS2 was triggered via the safety bus.
Bit 10 SS2 through error SS2 was triggered through an error.
Bit 11 Reserved −
Bit 12 SLS1 via SD−In SLS1 was triggered via a safe input.
Bit 13 SLS1 via S−bus SLS1 was triggered via the safety bus.
Bit 14 SLS1 via OMS SLS1 was triggered via the operating mode changeover.
Bit 15 Reserved −
Bit 16 SLS2 via SD−In SLS2 was triggered via a safe input.
Bit 17 SLS2 via S−bus SLS2 was triggered via the safety bus.
Bit 18 SLS2 via OMS SLS2 was triggered via the operating mode changeover.
Bit 19 Reserved −
Bit 20 SLS3 via SD−In SLS3 was triggered via a safe input.
Bit 21 SLS3 via S−bus SLS3 was triggered via the safety bus.
Bit 22 SLS3 via OMS SLS3 was triggered via the operating mode changeover.
Bit 23 Reserved −
Bit 24 SLS4 via SD−In SLS4 was triggered via a safe input.
Bit 25 SLS4 via S−bus SLS4 was triggered via the safety bus.
Bit 26 SLS4 via OMS SLS5 was triggered via the operating mode changeover.
Bit 27 Reserved −
Bit 28 SDIpos via SD−In SDIpos was triggered via a safe input.
Bit 29 SDIpos via S−bus SDIpos was triggered via the safety bus.
Bit 30 SDIpos via SLS SDIpos was triggered in combination with SLS.
Bit 31 SDIpos in normal operation SDIpos was triggered in normal operation.
Bit 32 SDIneg via SD−In SDIneg was triggered via a safe input.
Bit 33 SDIneg via S−bus SDIneg was triggered via the safety bus.
Bit 34 SDIneg via SLS SDIneg was triggered in combination with SLS.
Bit 35 SDIneg in normal operation SDIneg was triggered in normal operation.
Bit 36 SLI is active SLI was triggered in special operation.
Bit 37 Reserved −
Bit 38 Reserved −
Bit 39 Reserved −
Bit 40 Special operation via SD−In Special operation was triggered vi a safe input.
Bit 41 Special operation via S−bus Special operation was triggered via the safety bus.
Bit 42 Reserved −
Bit 43 Reserved −
Bit 44 ES via SD−In ES was triggered via a safe input.
Bit 45 ES via S−bus ES was triggered via the safety bus.
Bit 46 Reserved −
Bit 47 Reserved −
