9300 Servo PLC
System blocks
2.4 AIF_IO_Management
2-15
L
ServoPLC EN 2.0
2.4 AIF_IO_Management
Automation interface management (module number 161)
This SB monitors for communication errors through a fieldbus module connected to the automation
interface (AIF).
• In the event of an error AIF_bCe0CommErr_b sets TRUE and initiates a CEO communication
error (LECOM no. 61). The response to this error can be configured under C0126 (default
setting: off).
• With later AIF modules (e.g. 2133 and 2175) AIF_bFieldBusStateBit0_b ...
AIF_bFieldBusStateBit7_b also transfers an error code from the fieldbus module.
Tip!
Please observe the corresponding Operating Instructions for the fieldbus module.
AIF_bCe0CommErr_b
AIF_bFieldBusStateBit0_b
AIF_bFieldBusStateBit1_b
AIF_bFieldBusStateBit2_b
AIF_bFieldBusStateBit6_b
AIF_bFieldBusStateBit5_b
AIF_bFieldBusStateBit4_b
AIF_bFieldBusStateBit3_b
AIF_bFieldBusStateBit7_b
AIF1_IO_Management
AIF
Communication
Error
AIF
Field Bus State
Fig. 2-7 AIF_IO_Management
VariableName
DataType SignalType Address DIS DIS format Note
AIF_bCe0CommErr_b %IX161.0.0 “CE0” communication error
AIF_bFieldBusStateBit0_b %IX161.1.0 Error number - bit 0
AIF_bFieldBusStateBit1_b %IX161.1.1 Error number - bit 1
AIF_bFieldBusStateBit2_b %IX161.1.2 Error number - bit 2
AIF_bFieldBusStateBit3_b
Bool binary
%IX161.1.3 Error number - bit 3
AIF_bFieldBusStateBit4_b
B
o
o
l
b
i
n
a
r
y
%IX161.1.4 Error number - bit 4
AIF_bFieldBusStateBit5_b %IX161.1.5 Error number - bit 5
AIF_bFieldBusStateBit6_b %IX161.1.6 Error number - bit 6
AIF_bFieldBusStateBit7_b %IX161.1.7 Error number - bit 7
CEO communication error
• Theresponsetoa“CE0” communication error can be set under C0126:
Code LCD
Possible settings
Info
o
Lenze Selection
o
C0126 MONIT CE0 3 Configuration
Communication error (CE0)
0TRIP
2 Warning
3Off
