3.4 Code table
How to read the code table:
Column Abbreviation Meaning
Code C0168
1
2
¼
8
Code C0168
Subcode 1 of code C0168
Subcode 2 of code C0168
¼
Subcode 8 of code C0168
[C0156] Parameter value of code can only be changed when controller is inhibited.
LCD Keypad LCD
Lenze
Factory setting of the code
g Display code (can only be displayed)
* The column ”Info” contains more information
Selection 1{1%}99Minimum value {smallest step/unit} maximum value
Info Additional information on code
Code LCD
Possible settings
Info
Lenze Selection
[C0002] Par load 0 Load parameter set
• Parameter set1 is automatically loaded after ever y
mains connection.
0 Load factory setting into RAM
1 Load parameter set 1 into the RAM
C0003 Par save 0 Save parameter set
0 Saving completed
1 Non-volatile saving of parameter set 1
C0004 Op display 56 Keypad opera ting display
• Keypad will indicate selected code in the operating
level if no other status indications of C0183 are active.
All available codes
[C0006] Op mode à Operating mode of motor control
à depending on C0086
• Change of C0086 resets value to the assigned default
setting
• Change of C0006 sets C0086 = 0!
• ESC (Extended Speed Control):
Speed control with incread speed steadiness for
operation with incremental encoder only (not resolver!)
.
2 Servo async Y Servo control asynchronous motors in star connection
3ServoPM-SMY Servo control snychronous motors in star connection
22 Servo async Servo control asynchronous motors in del ta connection
31 ASM Y - ESC Servo control asynchronous motors in star connection,
ESC
32 PM-SM Y - ESC Servo control synchronous motors in star connection, ESC
33 ASM - ESC Servo control asynchronous motors in delta connection,
ESC
C0009 LECOM address 1 LECOM controller address
(bus device number for operatio n via interface)
• 10, 20, ..., 90 reserved for broadcast to device groups
for RS232, RS485, fibre optics.
1 {1} 99
