Inverter I55AP211B..7 I55AP211D..7 I55AP215B..7 I55AP215D..7 I55AP222B..7 I55AP222D..7
Rated power kW 1.1 1.1 1.5 1.5 2.2 2.2
Rated power hp 1.5 1.5 2 2 3 3
Mains voltage range 1/PE AC 170 V...264 V, 45 Hz...65 Hz
Output voltage 3 AC 0-230/240 V
Rated mains current
without mains choke A 14.3 14.3 16.7 16.7 22.5 22.5
Apparent output power kVA 2.2 2.2 2.6 2.6 3.6 3.6
Rated output current
2 kHz A 6 6 7 7 9.6 9.6
4 kHz A 6 6 7 7 9.6 9.6
8 kHz A 6 6 7 7 9.6 9.6
12 kHz A 5.4 5.4 6.3 6.3 8.6 8.6
16 kHz A 4 4 4.7 4.7 6.4 6.4
Power loss
2 kHz W 38 38 45 45 62 62
4 kHz W 40 40 48 48 66 66
8 kHz W 51 51 61 61 85 85
12 kHz W 54 54 65 65 91 91
16 kHz W 49 49 58 58 81 81
when the controller is
inhibited
W 6 6 6 6 6 6
Cyclic mains switching 3 mes per minute
Max. shielded motor cable
length
without EMC category m 50 50 50 50 50 50
Category C2 (2 kHz, 4 kHz, 8
kHz)
m 10 - 10 - 10 -
Category C3 (2 kHz, 4 kHz, 8
kHz)
m 35 - 35 - 35 -
Weight kg 2.7 2.6 2.7 2.6 2.7 2.6
Weight lb 6 5.7 6 5.7 6 5.7
Technical data
1-phase mains connecon 230/240 V
Rated data
