3-phase mains connecon 230/240 V
Rated data
Inverter I55AP137D..7 I55AP155D..7 I55AP175D..7 I55AP211D..7 I55AP215D..7 I55AP222D..7
Rated power kW 0.37 0.55 0.75 1.1 1.5 2.2
Rated power hp 0.5 0.75 1 1.5 2 3
Mains voltage range 3/PE AC 170 V...264 V, 45 Hz...65 Hz
Output voltage 3 AC 0-230/240 V
Rated mains current
without mains choke A 3.9 4.8 6.4 7.8 9.5 13.6
Apparent output power kVA 0.9 1.2 1.6 2.2 2.6 3.6
Rated output current
2 kHz A 2.4 3.2 4.2 6 7 9.6
4 kHz A 2.4 3.2 4.2 4 7 9.6
8 kHz A 2.4 3.2 4.2 6 7 9.6
12 kHz A 2.2 2.9 3.8 5.4 6.3 8.6
16 kHz A 1.6 2.1 2.8 4 4.7 6.4
Power loss
2 kHz W 19 24 30 38 45 62
4 kHz W 20 25 32 40 48 66
8 kHz W 24 31 40 51 61 85
12 kHz W 23 30 38 54 65 91
16 kHz W 22 28 35 49 58 81
when the controller is
inhibited
W 6 6 6 6 6 6
Cyclic mains switching 3 mes per minute
Max. shielded motor cable
length
without EMC category m 50 50 50 50 50 50
Weight kg 1.7 1.7 1.7 2.6 2.6 2.6
Weight lb 3.7 3.7 3.7 5.7 5.7 5.7
Inverter I55AP230C..7 I55AP240C..7 I55AP255C..7 I55AP275C..7 I55AP311C..7
Rated power kW 3 4 5.5 7.5 11
Rated power hp 4 5 7.5 10 15
Mains voltage range 3/PE AC 170 V...264 V, 45 Hz...65 Hz
Output voltage 3 AC 0-230/240 V
Rated mains current
without mains choke A 15 20.6 28.8 36.3 52.2
Apparent output power kVA 4.9 6.4 8.7 11 16
Rated output current
2 kHz A 12 16.5 23 29 42
4 kHz A 12 16.5 23 29 42
8 kHz A 12 16.5 23 29 42
12 kHz A 12 14.9 20.7 26.1 37.8
16 kHz A 12 11 15.3 19.3 28
Power loss
2 kHz W 79 102 137 172 242
4 kHz W 84 108 145 183 258
8 kHz W 109 140 189 238 337
12 kHz W 104 133 180 255 361
16 kHz W 104 133 180 227 321
when the controller is
inhibited
W 6 6 6 6 6
Cyclic mains switching 3 mes per minute
Max. shielded motor cable
length
without EMC category m 50 50 50 50 50
Weight kg 4.8 4.8 4.8 5 5
Weight lb 10.6 10.6 10.6 11 11
Technical data
3-phase mains connecon 230/240 V
Rated data
