9400 HighLine | Commissioning guide
Diagnostics
40 L EDB94AXX6954 DE/EN/FR/ES/IT 4.0
Drive diagnostics with the »Engineer«
Diagnostics tab
All parameters tab "Diagnostics" category
Response to errors
According to the selected response to an error, the state of the internal device control
changes, inhibits the controller, and switches on the LED "DRIVE ERROR":
Reset of error message
An error message with the response "Fault", "Quick stop by trouble" or "Warning locked"
must be explicitly reset (acknowledged) after the cause of the error has been eliminated.
Device command C00002 = "43: Reset fault"
Response Logbook entry Display under
C00168
Pulse inhibit Controller inhibit Acknowledgeme
nt required
LED
"DRIVE ERROR"
None OFF
Fault ;;;;;
Trouble ;;;;
(after 0.5 s)
Quick stop by
trouble
;; ;
Warning locked ;; ;
Warning ;;
Information ; OFF
System fault ;;;;Mains
switching
is required!
Danger!
If the fault has been removed, the drive is able to restart automatically from the
"Trouble" device state.
The automatic restart with enabled controller is configured via the code C00142.
