Function library
Digital input signals
Description
8
l
43
LDEDS−CCU210B EN 4.0
Codes for parameter setting
Code Possible settings Description
No. ñò < Byte Lenze Selection
C0406 Switch−on delay of digital input
signals
LOW ð HIGH ...
^ 42
1
RW EXT 4
0
0 {ms} 10000
... DIN1
2 0 ... DIN2
3 0 ... DIN3
4 0 ... DIN4
5 0 ... DIN5
6 0 ... DIN6
7 0 ... DIN7
8 0 ... DIN8
9 0 ... SS1 positive half wave
10 0 ... SS1 negative half wave
11 0 ... SS1 full−wave
12 0 Reserved
13 0 ... SS2 positive half wave
14 0 ... SS2 negative half wave
15 0 ... SS2 full−wave
16 0 Reserved
C0407 Switch−off delay of digital input
signals
HIGH ð LOW ...
^ 42
1
RW EXT 4
0
0 {ms} 10000
... DIN1
2 0 ... DIN2
3 0 ... DIN3
4 0 ... DIN4
5 0 ... DIN5
6 0 ... DIN6
7 0 ... DIN7
8 0 ... DIN8
9 0 ... SS1 positive half wave
10 0 ... SS1 negative half wave
11 0 ... SS1 full−wave
12 0 Reserved
13 0 ... SS2 positive half wave
14 0 ... SS2 negative half wave
15 0 ... SS2 full−wave
16 0 Reserved
