Lenze LDEC Series - Open Brake Function

Function library
Motor control
"Open brake" function
8
l
56
LDEDS−CCU210B EN 4.0
DescriptionPossible settingsCode
SelectionLenzeByte<ñòNo.
C0444 Deceleration ramp Vx ð VLx for ...
^ 55
1
RW EXT 4
50
1 {Hz/s} 255
... Frequency limitation 1
2 50 ... Frequency limitation 2
3 50 ... Frequency limitation 3
4 50 ... Frequency limitation 4
8.5.4 "Open brake" function
You can also open the motor brake via digital signal sources (C0410/15) without using the
"Motor V1−V8" functions.
In order to prevent an overload of the brake by triggering it for too long, a maximum
triggering time can be parameterised via C0451. After this time has elapsed, the brake
automatically engages even if a trigger signal is available.
If the "Motor V1−V8" functions are active, the motor brake always is open automatically.
Codes for parameter setting
Code Possible settings Description
No. ñò < Byte Lenze Selection
C0450 RW EXT 4 0
"Open brake" function:
configuration
^ 56
0 Brake opens immediately Brake opens if C0410/15 = HIGH
1 Brake opens with delay Brake opens if C0410/15 = HIGH
and drive frequency = 0 Hz
C0451 RW EXT 4 0
"Open brake" function:
maximum activation time
^ 56
0 {s} 1000 l C0451 = 0 s:
– Brake opens if
C0410/15 = HIGH
– Brake closes if
C0410/15 = LOW
l C0451 > 0 s:
– Brake opens if
C0410/15 = HIGH
– Brake closes after the time set
if C0410/15 = HIGH
