8.11 Open and closed loop control
A virtual set position is continuously calculated from the setpoint frequency specified,
which is usually determined via HWC code range. This set position is compared to the
actual position, which is determined by means of an actual value encoder (e.g. incremental
encoder), and is compensated correspondingly. It is attempted to reach the rated slip of the
motor by reducing the boost voltage and to compensate greater system deviations by
adapting the actual frequency.
For setting the control, only the encoder constant [Inc/m], the gearbox factor [mm/min],
and the control limitation [Hz/10] have to be parameterised.
For monitoring, an error message can be generated when a parameterisable maximally
permissible system deviation is exceeded. Furthermore a corresponding error message for
the event that the control is active and the feedback (e.g. defective pulse encoder) is not
working is output.
Codes for parameter setting
Code Possible settings Description
No. ñò < Byte Lenze Selection
C0129 RW EXT 4 0
Configuration of encoder error
monitoring
^ 70
0 Off
1 Error
2 Warning
C0130 RW EXT 4 0
Configuration of error monitoring
system deviation
^ 70
0 Off
1 Error
2 Warning
C0250 RW EXT 1 0
HWC code range control mode
^ 70
0 No control
1 Control active
2 Control with pick−up after stop
function
C0257 RW EXT 4 5.0
HWC control limitation (± of
setpoint frequency)
^ 70
1.0 {Hz} 10.0
C0258 RW EXT 2 200
HWC maximum system deviation
^ 70
2 {mm} 5000
C0261 RW EXT 2 1000
Encoder constant
^ 70
50 {inc/m} 5000
